Wizz 1.5HP Centrifugal Water Pump WHF5A

WiZZ WHF/5A 1.5HP Centrifugal Water Pump

Efficient Water Transfer, Built for Continuous Duty

The WiZZ WHF/5A Centrifugal Water Pump combines Italian technology with durable engineering to deliver reliable water transfer for domestic, agricultural, and industrial applications. Powered by a 1.5HP motor, this pump ensures strong flow rates, dependable pressure, and safe continuous operation with built‑in thermal protection.

Key Features

• Powerful 1.5HP Motor: Consistent performance for heavy‑duty water transfer.

• High Flow Capacity: Up to 650 L/min for large‑scale applications.

• Reliable Pressure: Maximum head of 13.8 m with efficient distribution.

• Durable Build: Cast iron body, corrosion‑resistant design, and brass impeller.

• Thermal Protection: Safeguards the motor during continuous operation.

• Italian Technology: Engineered for efficiency and long service life.

Technical Specifications

• Model: WHF/5A

• Flow Rate (Q): 100 – 600 L/min

• Maximum Flow (Qmax): 650 L/min

• Head (H): 13.8 – 3 m

• Maximum Head (Hm max): 4.5 m

• Motor Power: 1.5HP (1.1 kW)

• Voltage: 220V, Single Phase

• Frequency: 60Hz

• Speed: 3450 rpm

• Current: 7.5 A

• Max Power Consumption: 1650W

• Capacitor: 20 μF, 450V

• Protection: IP44, thermally protected

• Duty: Continuous

Why Choose WiZZ WHF/5A?

• Trusted for irrigation, water supply, and industrial transfer

• Combines power, efficiency, and durability in one unit

• Safe for continuous duty with thermal protection

• Backed
